FEATURES
– 1/10/25/40/50 Gb/s speeds
– Single and dual-port options
– Virtualization
– Low latency RDMA over Converged Ethernet(RoCE)
– Mellanox Multi-Host technology connects up to 4 independent hosts
– CPU offloading of transport operations – Application offloading
– Mellanox PeerDirect communication acceleration
– Hardware offloads for NVGRE, VXLAN and GENEVE encapsulated traffic
– End-to-end QoS and congestion control
– Hardware-based I/O virtualization
– RoHS compliant
– ODCC compatible
– Various form factors available
BENEFITS
– High performance boards for applications requiring high bandwidth, low latency and high message rate
– Industry leading throughput and latency for Web 2.0, Cloud and Big Data applications
– Smart interconnect for x86, Power, ARM, and GPU-based compute and storage platforms
– Cutting-edge performance in virtualized overlay networks
– Efficient I/O consolidation, lowering data center costs and complexity
– Virtualization acceleration – Power efficiency
ConnectX-4 Lx EN Ethernet Adapter
MCX4111A-XCAT 10GbE single-port SFP28, PCIe 3.0 x8, tall bracket
MCX4121A-XCAT 10GbE dual-port SFP28, PCIe3.0 x8, tall bracket
MCX4121A-XCHT 10GbE dual-port SFP28, PCIe3.0 x8, UEFI Enabled, tall bracket with host management
MCX4111A-ACAT 25GbE single-port SFP28, PCIe3.0 x8, tall bracket
MCX4121A-ACAT 25GbE dual-port SFP28, PCIe3.0 x8, tall bracket
MCX4111A-ACUT 25GbE single-port SFP28, PCIe3.0 x8, UEFI Enabled, tall bracket
MCX4121A-ACUT 25GbE dual-port SFP28, PCIe3.0 x8, UEFI Enabled, tall bracket
MCX4121A-ACST 25GbE dual-port SFP28, PCIe3.0 x8, tall bracket Secure Firmware
MCX4131A-BCAT 40GbE single-port QSFP28, PCIe3.0 x8, tall bracket
MCX4131A-GCAT 50GbE single-port QSFP28, PCIe3.0 x8, tall bracket
