  • BROADCOM SAS MegaRAID 9460-8i 05-50011-02 8-Ports tri-mode 2 x SFF8643 2GB DDR4 PCIe Controller
  • BROADCOM SAS MegaRAID 9460-8i 05-50011-02 8-Ports tri-mode 2 x SFF8643 2GB DDR4 PCIe Controller
BROADCOM SAS MegaRAID 9460-8i 05-50011-02 8-Ports tri-mode 2 x SFF8643 2GB DDR4 PCIe Controller BROADCOM SAS MegaRAID 9460-8i 05-50011-02 8-Ports tri-mode 2 x SFF8643 2GB DDR4 PCIe Controller

BROADCOM SAS MegaRAID 9460-8i 05-50011-02 8-Ports tri-mode 2 x SFF8643 2GB DDR4 PCIe Controller

  • Product description: BROADCOM SAS MegaRAID 9460-8i 05-50011-02 8-Ports tri-mode 2 x SFF8643 2GB DDR4 PCIe Controller
  • INQUIRY
Specifications
I/O Processor / SAS Controller SAS3508 dual-core RAID-on-Chip (ROC)
What's in the box MegaRAID SAS 9361-16i, QIG, LP bracket
Generation 12 Gb/s
Management Software LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure)
Cache Protection CacheVault CVPM05
Physical Dimensions Low profile 6.127” x 2.712”
Host Bus Type x8 lane PCI Express® 3.1
Cache Memory 2GB 2133 MHz DDR4 SDRAM
Internal Ports 8
Data Transfer Rates 12 Gb/s SAS-3 and 8 GT/s PCIe Gen 3 (NVMe) Compliant
Devices Supported SAS/SATA: 255, NVMe: 4 x4, up to 24 x2 or x4*
Internal Connectors 2 Mini-SAS HD x4 SFF-8643
Operating Temperature 10° to 55° C
Operating Voltage (V) +12V +/-8%, 3.3V +/-9%
OS Microsoft Windows. Contact Oracle support for Oracle Solaris driver or software support. See www.broadcom.com/support/down-load-serach for details on versions.
Regulatory Certifications Australia/New Zealand (AS/NZS CISPR 22), Canada (ICES -003, Class B), Europe (EN55022/EN55024), Japan (VCCI V-3), Korea (RRA no 2013-24 & 25), RoHS compliant, Safety: EN/IEC/UL 60950, Taiwan (CNS 13438), USA (FCC 47 CFR part 15 Subpart B, class B), WEEE
Warranty 3 years
