9560-16i Broadcom 05-50077-00 12G 8-port(2*SFF-8654) 8GB PCIe x8 Gen 4.0 RAID Controller

Product	Manufacturer Part #	What's in the Box
MegaRAID 9560-16i	05-50077-00	MegaRAID 9560-16i, FH (attached), LP bracket
CacheVault CVPM05	05-50039-00	CacheVault Power Module (CVPM05) with 24" remote extender

Specification	Value
Lifecycle	Active
Distributor Inventory	No
Cache Memory	8GB
Cache Protection	CacheVault CVPM05
Data Transfer Rates	12Gb/s SAS and 16GT/s PCIe Gen4 (NVMe) compliant
Devices Supported	SAS/SATA: 240, NVMe: 32
Generation	12 Gb/s
Host Bus Type	x8 lane PCI Express 4.0
I/O Processor / SAS Controller	SAS3916 12Gb/s SAS Tri-Mode RAID-on-Chip (ROC)
Internal Connectors	2 x8 SFF-8654 (SlimSAS)
Internal Ports	16
Management Software	LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure)
MTBF	>3,000,000 hours at 40° C
Operating Temperature°C	0°C to 55°C
OS	Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD
Physical Dimensions	155.52 (+/-0.13) mm x 68.77 (+/-0.13) mm
RAID Levels	0, 00, 1, 10, 5, 6, 60
Regulatory Certifications	Australia/New Zealand (AS/NZS CISPR 22), Canada (ICES -003, Class B), Europe (EN55022/EN55024), Japan (VCCI V-3), Korea (RRA no 2013-24 & 25), RoHS compliant, Safety: EN/IEC/UL 60950, Taiwan (CNS 13438), USA (FCC 47 CFR part 15 Subpart B, class B), WEEE
Warranty	3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba
