  • 9670-24I 24G 24-ports(3xSFF-8654) 8Gb Cache PCIe X8 4.0 FH RIAD Controller 05-50123-00
  • 9670-24I 24G 24-ports(3xSFF-8654) 8Gb Cache PCIe X8 4.0 FH RIAD Controller 05-50123-00
9670-24I 24G 24-ports(3xSFF-8654) 8Gb Cache PCIe X8 4.0 FH RIAD Controller 05-50123-00 9670-24I 24G 24-ports(3xSFF-8654) 8Gb Cache PCIe X8 4.0 FH RIAD Controller 05-50123-00

9670-24I 24G 24-ports(3xSFF-8654) 8Gb Cache PCIe X8 4.0 FH RIAD Controller 05-50123-00

  • Product #:9670-24i
  • MPN # : 05-50123-00
  • Product description: 05-50123-00 9670-24I 24Ports SFF-8654 8Gb Cache 24Gb SAS/NVMe RIAD Controller - Full Height
  • INQUIRY


Product Manufacturer Part # What's in the Box
MegaRAID 9670-24i

05-50123-00

MegaRAID 9670-24i, FH (attached)

CVPM05 05-50039-00 CacheVault Power Module (CVPM05) with 24" remote extender


Specification Value
Lifecycle Active
Distributor Inventory No
Cache Memory 8GB
Cache Protection CacheVault CVPM05
Connectors 3x8 SFF-8654
Devices Supported SAS/SATA: 240, NVMe: 32
Generation 24G
Internal Ports 24
Management Software LSI Storage Authority (LSA), StorCLI2 (Command-Line Interface), HII (UEFI Human Interface Infrastructure
MTBF >3,000,000 hours at 40° C
Operating Humidity 5% to 90% Non-condensing
Operating Temperature°C 0°C to 55°C
OS Support Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu Linux, CentOS Linux, Debian Linux, Oracle Enterprise Linux, FreeBSD
Physical Dimensions 6.1279" x 4.3759" (155.65mm x 111.15mm)
RAID Levels 0, 1, 5, 6, 10, 50, 60
Regulatory Certifications Australia/New Zealand RCM (AS/NZS CISPR 32; CISPR 32:2015, Class A; AS/NZS CISPR 32:2015, Class A), Canada EMC (ICES-003:2016 Issue 6: 2016, Class A; CAN/CSA CISPR 22-10; CISPR 22:2008), Europe (CE) (EN 55024, EN 55032, EN 55035; EN 55032:2015 +AC:2016, Class A; EN 55024:2010 +A1:2015; EN 55035:2017 +A11:2020), Korea (KN32/KN35), Taiwan BSMI (CNS 13438; CNS15663), USA/Canada Safety (UL Listed) (UL 62368-1, Second Edition; CAN/CSA C22.2 No. 62368-1-14), USA/Canada (FCC) (47 CFR FCC Part 15, Subpart B, Class A; ANSI C63.4:2014; CISPR 32:2008) CB (IEC 62368-1:2014 (Second edition); EN 62368-1:2014+A11: 2017), Japan (V-3/2015.04, Class A; V-4/2012.04; VCCI-CISPR 32:2016; CISPR 32:2015), Morocco (CMIM) (EN 55024, EN 55032, EN 55035; EN 55032:2015 +AC:2016, Class A; EN 55024:2010 +A1:2015; EN 55035:2017 +A11:2020); RoHS, WEEE
Typical Power 28W
Warranty 3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba
