9540-8i 05-50134-03 12 Gb/s 1x8 SFF-8654 PCIe x8 4.0 SAS3808 IMR RAID controller
- Product #：9540-8i
- MPN : 05-50134-03
- Product description: 9540-8i 05-50134-03 12 Gb/s 1x8 SFF-8654 PCIe x8 4.0 SAS3808 IMR RAID controller
| Product | Manufacturer Part # | What's in the Box |
|---|---|---|
| MegaRAID 9540-8i |
05-50134-03 |
MegaRAID 9540-8i, FH (attached) and LP brack |
| Specification | Value |
|---|---|
| Lifecycle | Active |
| Distributor Inventory | No |
| Data Transfer Rates | 12Gb/s SAS and 16GT/s PCIe Gen4 (NVMe) compliant |
| Devices Supported | SAS/SATA: 63, NVMe: 4 |
| Generation | 12 Gb/s |
| Host Bus Type | x8 lane PCI Express 4.0 |
| I/O Processor / SAS Controller | SAS3808 |
| Internal Connectors | 1 x8 SFF-8654 (SlimSAS) |
| Internal Ports | 8 |
| Management Software | LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure) |
| MTBF | >3,000,000 hours at 40° C |
| Operating Temperature°C | 0°C to 55°C |
| OS | Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD |
| Physical Dimensions | 155.52 (+/-0.13) mm x 68.77 (+/-0.13) mm |
| RAID Levels | 0, 00, 1, 10 |
| Regulatory Certifications | Australia/New Zealand (AS/NZS CISPR 22), Canada (ICES -003, Class B), Europe (EN55022/EN55024), Japan (VCCI V-3), Korea (RRA no 2013-24 & 25), RoHS compliant, Safety: EN/IEC/UL 60950, Taiwan (CNS 13438), USA (FCC 47 CFR part 15 Subpart B, class B), WEEE |
| Typical Power | 6.0W |
| Warranty | 3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba |
