  • 9580-8i8e BROADCOM 05-50076-00 12G 8 int.+ 8 etx. Ports 8Gb Cache x8 PCIe Gen 4.0 RAID Controller
  • 9580-8i8e BROADCOM 05-50076-00 12G 8 int.+ 8 etx. Ports 8Gb Cache x8 PCIe Gen 4.0 RAID Controller
9580-8i8e BROADCOM 05-50076-00 12G 8 int.+ 8 etx. Ports 8Gb Cache x8 PCIe Gen 4.0 RAID Controller9580-8i8e BROADCOM 05-50076-00 12G 8 int.+ 8 etx. Ports 8Gb Cache x8 PCIe Gen 4.0 RAID Controller

9580-8i8e BROADCOM 05-50076-00 12G 8 int.+ 8 etx. Ports 8Gb Cache x8 PCIe Gen 4.0 RAID Controller

  • Product #:9580-8i8e
  • MPN: 05-50076-00
  • Product description: Boost performance and deploy a seamless operation of SAS, SATA and NVMe storage devices from any system with PCIe 4.0 RAID controller
  • INQUIRY


Product Manufacturer Part # What's in the Box
MegaRAID 9580-8i8e

05-50076-00

MegaRAID 9580-8i8e, FH (attached), LP bracket

CacheVault CVPM05 05-50039-00 CacheVault Power Module (CVPM05) with 24" remote extender


Specification Value
Lifecycle Active
Distributor Inventory No
Cache Memory 8GB
Cache Protection CacheVault CVPM05
Data Transfer Rates 12Gb/s SAS and 16GT/s PCIe Gen4 (NVMe) compliant
Devices Supported SAS/SATA: 240, NVMe: 32
External Connectors 2 x4 SFF-8644
External Ports 8
Generation 12 Gb/s
Host Bus Type x8 lane PCI Express 4.0
I/O Processor / SAS Controller SAS3916 12Gb/s SAS Tri-Mode RAID-on-Chip (ROC)
Internal Connectors 1 x8 SFF-8654 (SlimSAS)
Internal Ports 8
Management Software

LSI Storage Authority (LSA),

StorCLI (Command-Line Interface),

HII (UEFI Human Interface Infrastructure)

MTBF >3,000,000 hours at 40° C
Operating Temperature°C 0°C to 55°C
OS

Microsoft Windows,

VMware vSphere/ESXi,

Red Hat Enterprise Linux,

SuSE Linux, Ubuntu Linux,

Citrix XenServer,

CentOS Linux,

Debian Linux,

Oracle Enterprise Linux,

Fedora,

FreeBSD

Physical Dimensions 167.52 (+/-0.13) mm x 68.77 (+/-0.13) mm
RAID Levels 0, 00, 1, 10, 5, 6, 60
Regulatory Certifications

Australia/New Zealand (AS/NZS CISPR 22),

Canada (ICES -003, Class B),

Europe (EN55022/EN55024),

Japan (VCCI V-3),

Korea (RRA no 2013-24 & 25),

RoHS compliant,

Safety: EN/IEC/UL 60950,

Taiwan (CNS 13438),

USA (FCC 47 CFR part 15 Subpart B, class B),

WEEE

Warranty 3 years
